ZX60-SERIES

Quiet. Wide. Flat.

Coaxial LNAs For Broadband Receivers, LO Chains, Test Setups & More

Mini-Circuits’ ZX60-series of coaxial LNAs continues to expand with four new wideband modules covering C-Band, X-Band and Ku-Band operation. The ZX60-series features Mini-Circuits' patented unibody housing construction, renowned for its ruggedness and compact size. With flat gain across their respective bands, low NF and additive phase noise, and excellent linearity, these new additions to the ZX60-series are well-suited to applications from 5G MIMO to satellite communications, test instrumentation, EW/ECM and more!

EXPLORE ZX60 SERIES

Key Features:

Low noise and additive phase noise
Flat gain over wide operating bandwidth
Excellent linearity
Rugged unibody connectorized housing

LATEST RELEASES

ZX60-Series LNAs

Model Name

ZX60-5123LN+

Description

Low Noise Amplifier, 1.4 dB NF, +29.5 dBm OIP3, SMA, 50Ω

F Low

5.5 GHz

F High

12.5 GHz

ZX60-5153LN+	Low Noise Amplifier, 1.5 dB NF, +28 dBm OIP3, SMA, 50Ω	5.5 GHz	15.5 GHz

ZX60-06183LPN+	Low Phase Noise Amplifier, -169 dBc/Hz APN @ 10 kHz offset, SMA, 50Ω	6 GHz	18 GHz

ZX60-06223LN+	Low Noise Amplifier, 2.8 dB NF, 22 dB Gain, +22.8 dBm OIP3, SMA, 50Ω	6 GHz	22 GHz
